AUX R32 C-Series — AJAN 36K BTU, 208/230V Heat Pump Mini-Split

Basis of Design: AUX AJAN36HP230V1C
Indoor Unit: AJAN36HP230V1CH
Outdoor Unit: AJAN36HP230V1CO
AHRI Certified Reference: 214290030

 PRODUCTS

2.1 Equipment

Manufacturer: AUX
Series: C-Series / C-SEER20
Model: AJAN36HP230V1C
System Type: Single-Zone Ductless Heat Pump
Refrigerant: R32

2.2 Cooling Performance

• Rated Cooling Capacity: 33,600 Btu/h
• Cooling Capacity Range: 7,500–35,500 Btu/h
• Rated Cooling Power Input: 3,320 W
• Moisture Removal: 3.6 kg/h
• Cooling Operating Range: 5°F to 125°F

2.3 Heating Performance

• Rated Heating Capacity @ 47°F: 34,000 Btu/h
• Heating Capacity Range: 7,500–35,500 Btu/h
• Maximum Heating Capacity @ -5°F: 17,000 Btu/h
• Heating Operating Range: -13°F to 75°F

2.4 Efficiency

• SEER2: 20
• HSPF2: 8.5
• COP: 3.3 W/W
• EER2: 10.1 Btu/h/W

2.5 Indoor Unit

• Airflow (SH/H/M/L/Q): 940 / 833 / 742 / 636 / – CFM
• Cooling Sound Pressure: 51 / 48 / 44 / 39 / 34 dB(A)
• Heating Sound Pressure: 50 / 48 / 43 / 39 / – dB(A)
• External Static Pressure: 0 in. w.g.

The manufacturer’s table lists the 36K indoor airflow at 940 / 833 / 742 / 636 CFM.

2.6 Outdoor Unit

• Outdoor Airflow: 2,000 CFM
• Cooling Sound Pressure: 59 dB(A)
• Heating Sound Pressure: 59 dB(A)

2.7 Refrigerant & Piping

• Refrigerant: R32
• Factory Refrigerant Charge: 72.3 oz
• Gas Line OD: 5/8 in.
• Liquid Line OD: 1/4 in.
• Indoor Drain: 5/8 in.
• Minimum Line Length: 10 ft
• Maximum Line Length: 100 ft
• Maximum Height Difference: 65 ft

The manufacturer sheet confirms R32 and a 72.3 oz factory charge for the 36K system

2.8 Electrical

• Power Supply: 208/230V, 1 Phase, 60 Hz
• Minimum Circuit Ampacity (MCA): 20 A
• Maximum Overcurrent Protection (MOCP): 35 A
• Recommended Breaker Size: 35 A
